Parameter
Chemical Composition
Mechanical Properties
Product nameBrass coil/strip
Size0.1-20mm;100-2500mm or customized
StandardASTM, AISI,JIS, DIN, EN,GOST
GradeC10200,C12000,C22000,C21000,C23000,C51900,C6191,C63200,C76400,C95300,C95500,C95800, etc.
Surfacemill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
ApplicationBrass coilcan be made to do all sorts of deep drawing and bending stress components,
such as manufacturing pins,rivets,gasket,nuts,conduits,the barometer spring,screen,
radiator parts, etc
PackageStandard export seaworthy or as customers' requirements
PaymentT/T,L/C
Delivery time7-15 days


GradeMain componentsImpurity components %total impurities %

CuPbZnFeNi
HPb59-157-600.8-1.9margin≤0.5≤1.0≤1.0
HPb59-257.5-59.52.0-2.8margin≤0.5--≤1.2
HPb59-357.5-59.52.0-3.0margin≤0.5≤0.5≤1.2
HPb60-258-611.5-2.5margin≤0.3--
HPb62-260-631.5-2.5margin≤0.15--
HPb62-360-632.5-3.7margin≤0.35--
HPb63-362-652.4-3.0margin≤0.1≤0.5≤0.75

Main components %Impurity components%

CuZnPb
FeNi
H5957-60margin≤0.5≤0.3≤0.5≤1.0
HP6257-60margin≤0.08≤0.15≤0.5≤0.5
H6563.5-68margin≤0.03≤0.1≤0.5≤0.3
H6867-70margin≤0.03≤0.1≤0.5≤0.3
H7068.5-71.5margin≤0.03≤0.1≤0.5≤0.3
H8079-81margin≤0.03≤0.1≤0.5≤0.3
H8584-86margin≤0.03≤0.1≤0.5≤0.3
H9088-91margin≤0.03≤0.1≤0.5≤0.2
H9695-97margin≤0.03≤0.1≤0.5≤0.2
Grade (JIS)TemperVickers Hardness (HV)Tensile Strength (Mpa)Elongation (%)
C1100,C1201,C1220,etc.M (Soft)≤70≥195≥30
Y4 (1/4H)60-95215-295≥25
Y2 (1/2H)80-110245-345≥8
C95800
O≥160≥585≥15
C63200TQ50
190-210≥620≥15


PACKING AND TRANSPORTATION
